Workshop OverView
-
The Machining and Fabrication Workshop mainly focuses on the processing of metal and cardboard. Equipped with a range of high-end equipment and various hand tools, it can not only produce precision parts but also create interesting cardboard models, transforming curiosity and creativity into practical technology and products.
Engineer
-
Training Introduction
The Machining and Fabrication Workshop regularly holds 6770 PDC courses and hands-on training activities aimed at helping students master the skills of mechanical processing. The course content is diverse, with hands-on projects as the main focus, combining education with entertainment. Students can participate in DIY projects such as making metal vases, bookmarks, etc., where they can not only learn theoretical knowledge but also cultivate hands-on skills and harvest interesting works.
-
Training Introduction
VIEW MORE
Workshop EQUIPMENT
-
CNC machining center
Equipment Introduction
Milling metal and nylon materials
Parameter
CNC System: FANUC 0IMF Plus CNC system
X/Y/Z Axis Positioning Accuracy: 0.006mm
Workbench Area: 890 mm*420 mm -
CNC lathe
Equipment Introduction
Turning rotary metal and nylon materials
Parameter
CNC System: FANUC CNC system
X/Z Axis Positioning Accuracy: 0.006/0.008mm
Spindle Speed: 0-6000r/min -
CNC Engraving Machine
Equipment Introduction
Turning rotary metal and nylon materials
Parameter
X/Y/Z Axis Positioning Accuracy: 0.010/0.010/0.008mm
Spindle Speed: MAX 36000rpm
CNC System: JD50 CNC system -
Intelligent Cutting Machine
Equipment Introduction
Cutting cardboard and EVA materials
Parameter
Maximum cutting thickness:50mm
Effective working size:1100mm x 1300mm
repeat accuracy:±0.05mm -
Shearing Machine
Equipment Introduction
Cutting metal sheets
Parameter
Maximum shear force: 210 KN
Blade length: 1620 mm -
Bench Drill
Equipment Introduction
Drilling and tapping
Parameter
Spindle speed: 800~4100r/min
maximum travel of spindle:100mm
Supplies
-
Machine tool cutters
-
Cardboard
-
Hardware materials
